Air Compressors (Diesel)

Air Compressor, 400CFM HP, Max. 200psi


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

Daily: $495.00

Weekly: $1,727.00

Monthly: $4,318.00

Quantity: for a period of
day(s) week(s) month(s)

**Insurance Requirements Mandate that A Major Credit Card, Drivers License and Signed Rental Agreement Is Required For the Rental Of This Equipment**
**Positive Air Shutoff Equipped Units Available**
SPECIFICATIONS
Weight (Wet) - 4700lbs / 2132KG
Trailer mounted (Inches) L x W x H - 167 x 72.8 x 80.6
Hitch: 2" 5/16 Ball
Fuel tank capacity - 197L
Fuel consumption at 0% load - L/Hr 11.4 - 15.1
Fuel consumption at 100% load - L/Hr 26.5
DEF tank capacity - 18.9L
DEF consumption at 100% load - L/Hr 1,25
Actual free air delivery (FAD) Cfm - 365 - 410
Normal effective working pressure Psi -150 - 200
Maximum unloading pressure Psi - N/A
Minimum working pressure Psi - 72
Max.sound pressure level @ 23 (7m) at normal working speed & pressure2 dB(a) 76
Compression Stages - 1
Air Receiver Capacity - 41.6L
Compressor oil capacity - 23.8L
Approximate air outlet temperature - C 93
Air Compressor outlets - 2 x & 1 x 1
Max. ambient temperature - C 50
Minimum starting temperature (with cold weather options) - C -25
Engine John Deere - 4045EWL
Emissions Regulation US EPA Tier - T4F
Output at rated speed (2400 rpm) - HP 148
Number of cylinders - 4
Aspiration - Turbocharged
Displacement - cu in (L) 269 (4.5)
Engine speed (Unloaded) - Rpm 2000
Engine speed (Maximum loaded) - Rpm 2200
Engine oil capacity - 20.4
Engine oil required - Low Ash Oil per API CJ-4, ACEA C9
Engine coolant capacity - 23.6L

Also check the following item(s) related to the above:

* Prices are subject to change.

* Please call us for any questions on our air compressor 400cfm hp max. 200psi rentals in Prince George BC.
